UNDERSTANDING THE ADV8003 HARDWARE MANUAL

DESCRIPTION OF THE HARDWARE MANUAL

This manual provides a detailed description of the functionality and features supported by the ADV8003.

DISCLAIMER

The information contained in this document is proprietary of Analog Devices Inc. (ADI). This document must not be made available to
anybody other than the intended recipient without the written permission of ADI.
The content of this document is believed to be correct. If any errors are found within this document or, if clarification is needed, contact
the authors at ATV_VSP_Apps@analog.com.

TRADEMARK AND SERVICE MARK NOTICE

The Analog Devices logo is a registered trademark of Analog Devices, Inc. All other brand and product names are trademarks or service
marks of their respective owners.

NUMBER NOTATIONS

Notation Description
bit N Bits are numbered in little endian format, that is, the least
significant bit of a number is referred to as Bit 0
V[X:Y] Bit field representation covering bit X to Y of a value or a field V
0xNN Hexadecimal (base-16) numbers are preceded by the prefix '0x'
0bNN Binary (base-2) numbers are preceded by the prefix '0b'
NN Decimal (base-10) are represented using no additional prefixes
or suffixes

REGISTER ACCESS CONVENTIONS

Mode Description
R/W Memory location has read and write access.
R Memory location has read access only. A read always returns 0
unless specified otherwise.
W Memory location has write access only.

ACRONYMS AND ABBREVIATIONS

This is a list of common acronyms and abbreviations found in Analog Devices Hardware Manuals.
Acronym/Abbreviation
ACP
ACR
ADC
AFE
AGC
Ainfo
AKSV
An
ARC
AUD_IN
AVI
Aux
Bcaps
Rev. B, August 2013
Description
Audio Content Protection
Audio Clock Regeneration
Analog to Digital Converter
Analog Front End
Automatic Gain Control
HDCP register. Refer to HDCP documentation.
HDCP Transmitter Key Selection Vector. Refer to HDCP documentation.
64-bit pseudo-random value generated by HDCP cipher function of device A
Audio Return Channel
Audio Input Pin
Auxiliary Video Information
Auxiliary
HDCP register. Refer to HDCP documentation.
