Function
pvsp_fieldbuffer4_addr
[31:0]
0x02495A00 
0xXXXXXXXX
pvsp_fieldbuffer5_addr[31:0], Primary VSP Map, Address 0xE814[7:0]; Address 0xE815[7:0]; Address 0xE816[7:0]; Address
0xE817[7:0]
This signal is used to set the start address of field/frame buffer 5. The software should arrange memory space properly, avoiding conflict
between different buffers.
Function
pvsp_fieldbuffer5_addr
[31:0]
0x02C7EA00 
0xXXXXXXXX
pvsp_fieldbuffer6_addr[31:0], Primary VSP Map, Address 0xE889[7:0]; Address 0xE88A[7:0]; Address 0xE88B[7:0]; Address 0xE88C[7:0]
This signal is used to set the start address of field/frame buffer 6. The software should arrange memory space properly, avoiding conflict
between different buffers.
Function
pvsp_fieldbuffer6_addr
[31:0]
0x03073200 
0xXXXXXXXX

3.2.1.5. Frame Latency

Different resolutions have different frame latencies, depending on the timing combination to and from the PVSP. This is due to the
increased processing required in converting and scaling video data.
resolutions.
Input
Frame rate
50 Hz
59.94/60 Hz
Rev. B, August 2013
Description
Default
Start address of field/frame buffer 4
Description
Default
Start address of field/frame buffer 5
Description
Default
Start address of field/frame buffer 6

Table 24: Frame Latency in Normal Mode

Output Frame Rate 50 Hz
Timing 576p/720p/1080
p
576i 1.1~2.3
1080i
576p 0.1~1.3
720p
1080p
480i 1.1~2.3
1080i
480p 0.1~1.3
720p
1080p
Table 24 lists the frame latencies in normal mode for various
59.94/60 Hz
480p/720p/1080p 720p/1080p
1, 2 1.1~2.3
0.1~1.3
1.1~2.3
0.1~1.3
151
ADV8003 Hardware Manual
23.97/24 Hz 25/30 Hz
720p/1080p
/4kx2k /4kx2k
1.1~2.4 1.1~2.4
0.1~1.4 0.1~1.4
0.1~3.4 0.1~1.4
3
0.1~3.4 0.1~1.4
4
