Function
aud_packet_id[7:0]
0xxxxxxx
1xxxxxxx
ms_packet_id[7:0], HDMI RX Infoframe Map, Address 0xE3E9[7:0]
This signal is a readback of the MPEG Source InfoFrame ID.
Function
ms_packet_id[7:0]
0xxxxxxx
1xxxxxxx
vs_packet_id[7:0], HDMI RX Infoframe Map, Address 0xE3EC[7:0]
This signal is a readback of the Vendor Specific InfoFrame ID.
Function
vs_packet_id[7:0]
0xxxxxxx
1xxxxxxx
acp_packet_id[7:0], HDMI RX Infoframe Map, Address 0xE3EF[7:0]
This signal is a readback of the ACP Packet ID.
Function
acp_packet_id[7:0]
0xxxxxxx
1xxxxxxx
isrc1_packet_id[7:0], HDMI RX Infoframe Map, Address 0xE3F2[7:0]
This signal is a readback of the ISRC1 Packet ID.
Function
isrc1_packet_id[7:0]
0xxxxxxx
1xxxxxxx
isrc2_packet_id[7:0], HDMI RX Infoframe Map, Address 0xE3F5[7:0]
This signal is a readback of the ISRC2 Packet ID.
Function
isrc2_packet_id[7:0]
0xxxxxxx
1xxxxxxx
gamut_packet_id[7:0], HDMI RX Infoframe Map, Address 0xE3F8[7:0]
This signal is a readback of the Gamut Metadata Packet ID.
Rev. B, August 2013
Description
Packet type value of packet stored in InfoFrame Map, Address 0x1C to 0x29
Packet type value of InfoFrame stored in InfoFrame Map, Address 0x1C to 0x29
Description
Packet type value of packet stored in InfoFrame Map, Address 0x46 to 0x53
Packet type value of InfoFrame stored in InfoFrame Map, Address 0x46 to 0x53
Description
Packet type value of packet stored in InfoFrame Map, Address 0x54 to 0x6F
Packet type value of packet stored in InfoFrame Map, Address 0x54 to 0x6F
Description
Packet type value of packet stored in InfoFrame Map, Address 0x70 to 0x8B
Packet type value of InfoFrame stored in InfoFrame Map, Address 0x70 to 0x8B
Description
Packet type value of packet stored in InfoFrame Map, Address 0x8C to 0xA7
Packet type value of InfoFrame stored in InfoFrame Map, Address 0x8C to 0xA7
Description
Packet type value of packet stored in InfoFrame Map, Address 0xA8 to 0xC3
Packet type value of InfoFrame stored in InfoFrame Map, Address 0xA8 to 0xC3
