USB on-the-go full-speed (OTG_FS)
Bits 1:0 DSPD: Device speed

43.15.33 OTG device control register (OTG_DCTL)

Address offset: 0x804
Reset value: 0x0000 0002
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:19 Reserved, must be kept at reset value.
Bit 18 DSBESLRJCT: Deep sleep BESL reject
Bits 17:12 Reserved, must be kept at reset value.
Bit 11 POPRGDNE: Power-on programming done
Bit 10 CGONAK: Clear global OUT NAK
Bit 9 SGONAK: Set global OUT NAK
Bit 8 CGINAK: Clear global IN NAK
Bit 7 SGINAK: Set global IN NAK
1564/1693
Indicates the speed at which the application requires the core to enumerate, or the
maximum speed the application can support. However, the actual bus speed is determined
only after the chirp sequence is completed, and is based on the speed of the USB host to
which the core is connected.
00: Reserved
01: Reserved
10: Reserved
11: Full speed (USB 1.1 transceiver clock is 48 MHz)
28 27 26 25
Res. Res. Res.
12 11 10 9
PO
CGO SGO
PRG
NAK NAK
DNE
rw w w
Core rejects LPM request with BESL value greater than BESL threshold programmed.
NYET response is sent for LPM tokens with BESL value greater than BESL threshold. By
default, the deep sleep BESL reject feature is disabled.
The application uses this bit to indicate that register programming is completed after a
wakeup from power down mode.
A write to this field clears the Global OUT NAK.
A write to this field sets the Global OUT NAK.
The application uses this bit to send a NAK handshake on all OUT endpoints.
The application must set the this bit only after making sure that the Global OUT NAK
effective bit in the Core interrupt register (GONAKEFF bit in OTG_GINTSTS) is cleared.
A write to this field clears the Global IN NAK.
A write to this field sets the Global non-periodic IN NAK.The application uses this bit to send
a NAK handshake on all non-periodic IN endpoints.
The application must set this bit only after making sure that the Global IN NAK effective bit
in the Core interrupt register (GINAKEFF bit in OTG_GINTSTS) is cleared.
24 23 22
Res. Res. Res.
8 7 6
CGI SGI
NAK NAK
w w rw
DocID024597 Rev 3
21 20 19 18
DS
Res. Res. Res. BESL
RJCT
rw
5 4 3 2
GON GIN
TCTL
STS STS
rw rw r r
RM0351
17 16
Res. Res.
1 0
RWU
SDIS
SIG
rw rw
