Error protocol

13 Error protocol
The various control methods and the hardware of the frequency inverter include functions which con-
tinuously monitor the application. The operational and error diagnosis is facilitated by the information
stored in the error protocol.
13.1

Error list

Last errors
The last 16 fault messages are stored in chronological order and the
number of errors which have occurred since initial commissioning of the frequency inverter. On the
operator panel, the error code FXXXX is displayed. The meaning of the error key is described in the
following chapter " 13.1.1 "Error messages". Via the PC user interface, the number of operation hours
(h), operation minutes (m) and the fault message can additionally be read out. The current operating
hours are shown by parameter
edged via the operator panel buttons or according to the link
No. Description
310 Last Error
311 Last Error but one
312 to 325
362 No. of Errors
363 No. of self acknowledged errors
Automatic error acknowledgment enables acknowledgment of errors Overcurrent F0507 and Overvolt-
age F0700 without intervention by an overriding control system or the user. The
363 shows the total number of automatic error acknowledgments.
edged errors
No. Description
363 No. of self acknowledged
Errors
Error list
Operating hours counter
Error list
hhhhh:mm ; FXXXX fault message.
hhhhh:mm ; FXXXX fault message.
Error 3 to error 16.
Number of errors occurred after the initial commissioning of the
frequency inverter.
Error list
Total number of automatic error acknowledg-ment with syn-
chronization.
325
No. of errors
245. The error message can be acknowl-
Error acknowledgement
Function
No. of self acknowl-
Function
06/2013 Operating Instructions
362 shows the
103.
