Options
12.3

Brake resistor

The brake resistors convert the regenerative energy into heat when the drive is braking.
The resistor must be selected according to the duty cycle and braking power.
Mains Typ3
volt-
age
V
230 BR 160/100
230 BR 432/37
230 BR 667/24
230 BR 1332/12
400 BR 213/300
400 BR 471/136
400 BR 696/92
400 BR 1330/48
400 BR 2000/32
400 BR 4000/16
400 BR 8000/7
Brake resistor
Resistor
Value Rated power
Ω kW
100 1,6
37 4,3
24 6,6
12 13,3
300 2,1
136 4,7
92 6,9
48 13,3
32 20
16 40
7,5 80
Continu- Maximum
ous power permissi-
ble oper-
ating
voltage
W V
160 900
432 900
667 900
1332 900
213 900
471 900
696 900
1330 900
2000 900
4000 900
8000 900
295
06/2013 Operating Instructions
Integrated
thermal protec-
tion
Optional
Optional
Ja
Ja
Optional
Optional
Ja
Ja
Ja
Ja
Ja
