574 Power Limit
575 Limitation Time
The threshold selected via parameter
573 is selected to motor or heat sink temperature monitoring, the power is reduced to the val-
Mode
ue of 574 once the limit value is reached. The power is reduced until the temperature
Power Limit
has dropped sufficiently. You can set an additional time
after falling below the limit value should be maintained. In motor operation, the output current and
the speed will be reduced. The load behavior of the motor must depend on the speed.
The power limit should be selected as small as possible in order to give the drive sufficient time to
cool down. The reference value is the rated output of the frequency inverter or the set rated power of
the motor.
Parameters
No. Description
574 Power Limit
575 Limitation Time
Output signals
Reaching of a limit – selected in
15 - Warning Current Limitation
Controller Current Limit.
16 -
Long Term Ixt
Controller Current Limit.
17 -
Short Term Ixt
18 - Controller Current Limit. Tc
Controller Current Limit.
19 -
Motor Temp.
Agile
Operating Instructions
Operation Mode
Min.
40.00%
5 min
573 – can be signaled via digital outputs.
Operation Mode
The intelligent current limits limit the output current.
The overload reserve for 60 s has been used up and the out-
put current is being limited.
The overload reserve for 1 s has been used up and the output
current is being limited.
Max. heat sink temperature T
limits are active.
Max. motor temperature reached. The intelligent current limits
are active.
214
06/2013
Parameter descriptions
573 is monitored. If parameter
575 for which the limitation
Limitation Time
Setting
Max. Fact. sett.
95.00% 80.00%
300 min 15 min
reached. The intelligent current
K
Operation
Control functions
