The rated magnetizing current determined during the guided commissioning procedure is set to an
optimized value and does not have to be adjusted.
718 Rated slip correction factor (asynchronous motor, field-orientated control)
The rotor time constant results from the inductivity of the rotor circuit and the rotor resistance. Due to
the temperature-dependence of the rotor resistance and the satura-tion effects of the iron, the rotor
time constant is also dependent on temperature and current. The load behavior and thus the rated
slip depend on the rotor time constant. The guided commissioning determines the machine data dur-
ing the parameter identification and sets the parameter
The value calculated by the rotor time constants can be read out via the actual value
227. Parameter identification (during guided commissioning "Setup") should be done
time constant
while the motor is cold.
Parameters
No. Description
718 Rated slip correction factor
383 Voltage constant (synchronous motor)
In Configuration 610 (parameter
behavior should be optimized by setting parameter
The auto-setup during the guided commissioning (setup) identifies the voltage constant of the syn-
chronous motor. If a value > 0 mV was entered before manually, the voltage constant will not be
determined during auto-setup. The entered value is maintained.
For the voltage constant, refer to the motor data sheet. In the motor data sheet, the value may be
V
indicated in . This value can be taken over for Parameter
U
1000
min
Parameters
No. Description
383 Voltage constant
If the guided commissioning (Setup) is not carried out, the auto-setup should be carried out via pa-
rameter
SETUP selection
Select one of the settings 10 ... 14 for
During the guided commissioning (via keypad and VPlus) for Bonfiglioli motors the voltage constant is
pre-allocated.
For Non-Bonfiglioli motors the voltage constant should be entered if it is known. If the voltage con-
stant is unknown, set
Voltage constant
matic calculation and measurement.
The voltage constant should be optimized after the guided commissioning procedure: In no-load op-
eration, set 50% of the rated speed. Change the voltage constant in small steps until parameter
225 displays the value 101% (±0.5%).
flux
In the case of motors with a very high number of pole pairs (e.g. higher than 20), it is
possible that the maximum setting range of the parameter is not sufficient. In this
case, divide the voltage constant by 10 and enter the value. The division by 10 is con-
sidered internally.
384 Stator inductance (synchronous motor)
In configuration 610 for the control of synchronous machines, the control behavior can be improved
for high dynamic requirements by setting the parameter
