7.10

Special functions

The configurable functions of the corresponding control methods enable another field of application of
the frequency inverters. The integration in the application is made easier by special functions.

7.10.1 Pulse width modulation

400 Switching Frequency
The motor noises can be reduced by changing over the parameter
duction of the switching frequency should be up to a maximum ration of 1:10 to the frequency of the
output signal for a sine-shaped output signal. The maximum possible switching frequency depends on
the drive output and the ambient conditions. For the required technical data refer to the correspond-
ing table and the device type diagrams.
Parameters
No. Description
400 Switching Frequency
The factory setting of parameter
30.
figuration
401 Min. Switching Frequency
The heat losses increase proportionally to the load point of the frequency inverter and the switching
frequency. The automatic reduction adjusts the switching frequency to the current operating state of
the frequency inverter in order to provide the output performance required for the drive task at the
greatest possible dynamics and a low noise level.
The switching frequency is adapted between the limits which can be set with the parameters
400 and
ing Frequency
er than or equal to the
Switching Frequency
Parameters
No. Description
401 Min. Switching Frequency
