7.6.5.2

Setting frequency

510 Setting Frequency
517 Setting Frequency Switch Off Delta
If operation mode 4 - "Setting frequency" is selected for a digital output, the corresponding output will
be active if the actual value
The relevant output is switched over again once the
510 minus
ting frequency
Signal source 164 - "Setting frequency" can be linked to the functions of the frequency inverter.
Parameters
No. Description
510 Setting Frequency
517 Setting Frequency Switch Off Delta
If
Setting Frequency Switch Off Delta
never reset after the first switching on. Set up fitting values during commissioning.
Operation mode OUT1D (X13.5)
Operation mode OUT2D (X10/relay)
Operation mode OUT3D (X11.6)
Digital: Source MFO1D
510
Setting frequency
For linking to functions
7.6.5.3

Reference value reached

549 Reference Value Reached: Tolerance Band
In operation mode 5 - "Reference frequency reached" for a digital output, a message is generated via
the corresponding output when the actual frequency has reached the reference value.
In operation mode 6 - "Reference percentage reached" for a digital output, a message is generated
via the corresponding output when the actual percentage has reached the reference value.
Signal source 163 - "Reference frequency reached" or 178 - "Reference percentage reached" can be
linked to the functions of the frequency inverter.
The hysteresis can be defined as a percentage of the adjustable range (Max - Min) via parameter
Reference Value Reached: Tolerance Band
Parameters
No. Description
Reference Value Reached: Toler-
549
ance Band
Agile
Operating Instructions
210 is greater than the value of
Stator frequency
Setting Frequency Switch Off Delta
Min.
0.00 Hz
0.00 Hz
531(digital output)
532
533 (digital input/output)
554 (multifunction output)
549.
Min.
0.01%
190
06/2013
210 drops below the value "
Stator frequency
517".
Setting
Max. Fact. sett.
999.99 Hz 3.00 Hz
999.99 Hz 2.00 Hz
517 >
Setting Frequency
or
or
4 - Setting frequency
or
Set the value [Hz].
164 - Setting frequency
Setting
Max.
20.00%
Control inputs and outputs
Parameter descriptions
510.
Setting Frequency
Set-
510 the output is
Fact. sett.
5.00%
