BONFIGLIOLI Agile Operating Instructions Manual page 346

No.
473 Ramp Frequency-Motorpoti
474 Operation Mode
475 Reference Frequency Source 1
476 Reference Percentage Source 1
477 Gradient Percentage Ramp
478 Actual Percentage Source
480 Fixed Frequency 1
481 Fixed Frequency 2
482 Fixed Frequency 3
483 Fixed Frequency 4
484 Reference Frequency RAM
485 Fixed Frequency 5
486 Fixed Frequency 6
487 Fixed Frequency 7
488 Fixed Frequency 8
489 JOG Frequency
492 Reference Frequency Source 2
493 Operation Mode
494 Reference Percentage Source 2
495 Operation Mode
PWM input/repetition frequency input/pulse train
496 Operation mode IN2D
497 Rep.Freq. : Divider
506 Trigger Threshold
507 Trigger Threshold
509 Ramp Percentage-Motorpoti
510 Setting Frequency
Setting Frequency Switch Off Del-
517
ta
518 Minimum Reference Percentage
519 Maximum Reference Percentage
520 Fixed Percentage 1
521 Fixed Percentage 2
522 Fixed Percentage 3
523 Fixed Percentage 4
524 Reference Percentage RAM
Agile
Operating Instructions
Parameters
Description
Motor potentiometer
Frequency reference channel
Reference percentage channel
Ref. perc. val. channel/ramp
PID controller (technology controller)
Fixed frequencies
Frequency reference channel
Reference percentage channel
Repetition frequency input
Brake Chopper
Motor chopper
Motor potentiometer
Digital outputs
Percentage value limits
Fixed percentages
346
06/2013
Unit Setting range
Hz/s 0.01 ... 999.99
- Selection
- Selection
- Selection
%/s 0 ... 60000
- Selection
Hz -999.99 ... 999.99
Hz -999.99 ... 999.99
Hz -999.99 ... 999.99
Hz -999.99 ... 999.99
Hz -999.99 ... 999.99
Hz -999.99 ... 999.99
Hz -999.99 ... 999.99
Hz -999.99 ... 999.99
Hz -999.99 ... 999.99
Hz -999.99 ... 999.99
- Selection
- Selection
- Selection
- Selection
- Selection
- 1 ... 8192
AGL202: 225.0 ... 1000.0
V
AGL402: 325.0 ... 1000.0
AGL202: 225.0 ... 1000.0
V
AGL402: 325.0 ... 1000.0
%/s 0.00 ... 600.00
Hz 0.00 ... 999.99
Hz 0.00 ... 999.99
% 0.00 ... 300.00
% 0.00 ... 300.00
% -300.00 ... 300.00
% -300.00 ... 300.00
% -300.00 ... 300.00
% -300.00 ... 300.00
% -300.00 ... 300.00
Parameters (Menu PARA)
Parameter list
Chapter
7.5.3.3.1
7.5.3
7.5.1
7.5.2
7.5.2.4
7.9.3
7.5.1.3
7.5.1.3
7.5.1.3
7.5.1.3
CM
7.5.1.3
7.5.1.3
7.5.1.3
7.5.1.3
7.5.1.6
7.5.1
7.5.1.2
7.5.2
7.5.2.2
7.6.7
7.6.7.2
7.10.4
7.10.5
7.5.3.3.2
7.6.5.2
7.6.5.2
7.5.2.1
7.5.2.1
7.5.2.3
7.5.2.3
7.5.2.3
7.5.2.3
CM
