Commissioning
6.7.4

Fan for heating, ventilation, air conditioning system

Parameters
30 Configuration
418 Minimum frequency
419 Maximum frequency
420 Acceleration (clockwise)
421 Deceleration (clockwise)
447 1st Blocking frequency
449 Frequency Hysteresis
475 Reference frequency source 1
492 Reference frequency source 2
Operation mode (reference frequency
493
source)
Operation mode terminal X11.6 (digital
558
input/output)
Operation mode (intelligent current
573
limits)
606 Type V/f characteristic
Operation mode (P68&P69=1
630
|P68&P69=0) (stopping behavior)
645 Operation Mode Flying Start
651 Operation mode (auto start)
1550 Operation mode energy saving function Automatic
1552 Energy saving function on
68 Start Clockwise
69 Start Anticlockwise
Operation mode OUT1D (X13.5) (digital
531
output)
532 Operation mode OUT2D (X10/relay)
Operation mode OUT3D (X11.6) (digital
533
input/output)
Applications
Recommenced setting
110 IM: sensorless control (V/f characteristic)
10 Hz
50 Hz
10 Hz/s
-0.01 Hz
0 Hz
0 Hz
1 - analog value MFI1A
0 - zero
1 - (+/- reference)
1 - Output OUT3D
11 - Ixt + Tc (limitation to overload and max. heat
sink temperature)
2 - quadratic
0 - (Coast to Stop | Coast to Stop)
2 - On, according to reference
1 - On
163 - Reference Frequency reached
71 - IN1D
7 - Off
2 - Run signal
103 - Inv. error signal
25 - Warning Mask
103
