Conveying plant

Parameters
30 Configuration
418 Minimum frequency
419 Maximum frequency
420 Acceleration (clockwise)
421 Deceleration (clockwise)
447 1st Blocking frequency
449 Frequency Hysteresis
475 Reference frequency source 1
492 Reference frequency source 2
Operation mode (reference frequency
493
source)
Operation mode (P68&P69=1
630
|P68&P69=0) (stopping behavior)
645 Operation Mode Flying Start
68 Start Clockwise
69 Start Anticlockwise
Operation mode OUT1D (X13.5) (digital
531
output)
532 Operation mode OUT2D (X10/relay)
Agile
Operating Instructions
110 IM: sensorless control (V/f characteristic)
10 Hz
53 Hz
5 Hz/s
5 Hz/s
0 Hz
0 Hz
1 - Analog Value MFI1A
0 - zero
1 - (+/- reference)
0 - (Coast to Stop | Coast to Stop)
2 - On, according to reference
71 - IN1D
7 - Off
2 - Run signal
103 - Inv. error signal
104
