21 Error protocol

The various control methods and the hardware of the frequency inverter include functions which
continuously monitor the application. The operational and error diagnosis is facilitated by the
information stored in the error protocol.
21.1

List of errors

The last 16 error signals are stored in chronological order and
errors which have occurred since initial commissioning of the frequency inverter. The error code
FXXXX is displayed in menu branch VAL of the control unit. For the meaning of the error code, refer to
the following chapter 21.1.1 "21.1.1". Via the PC user interface, the number of operation hours (h),
operation minutes (m) and the error signal can additionally be read out. The current operating hours
can be read out via
Operation Hours Counter
keys of the operating unit and according to
No. Description
310 Last Error
311 Last Error but one
312 to 325
362 No. of Errors
The error and warning behavior of the frequency inverter can be set in various ways. The automatic
error acknowledgment enables acknowledgment of the faults Overcurrent F0500, Overcurrent F0507
and Overvoltage F0700 without intervention by an overriding control system or the user. The
self acknowledged Errors
No. Description
363 No. of self acknowledged
Errors
21.1.1

Error messages

The error code saved after a fault consists of the error group FXX and the code number XX.
Key
F00 00 No fault has occurred.
F01 00 Frequency inverter overloaded.
02 Frequency inverter overloaded (60 s), check load behavior
F01
03 Short-term overload (1 s), check motor and application parameters
Table "Fault Messages" continued on next page.
Key
00 Heat sink temperature too high, check cooling system and fan.
F02
01 Temperature sensor defective or ambient temperature too low.
F03 00 Interior temperature too high, check cooling system and fan.
12/16
245. The error message can be acknowledged via the
Error Acknowledgment
List of errors
hhhhh:mm ; FXXXX error message.
hhhhh:mm ; FXXXX error message.
Error 3 to error 16.
Number of errors occurred after the initial commissioning of the
frequency inverter.
363 shows the total number of automatic error acknowledgments.
List of errors
Total number of automatic error acknowledgment with
synchronization.
Error messages
Overload
Heat sink
Interior
Operating Instructions ACU
No. of Errors
103.
Function
Function
Meaning
Meaning
362 shows the number of
No. of
