Analog inputs
Multi-function MFI1
P452 1 Voltage 0...10 V
2 Current 0...20 mA
5 Current 4...20 mA
6 Voltage, charact.
7 Current, charact.
P454 Point X1 (2%)
P455 Point Y1 (0%)
P456 Point X2 (98%)
P457 Point Y2 (100%)
Multi-function MFI2
P562 1 Voltage 0...10 V
2 Current 0...20 mA
5 Current 4...20 mA
6 Voltage, charact.
7 Current, charact.
P564 Point X1 (2%)
P565 Point Y1 (0%)
P566 Point X2 (98%)
P567 Point Y2 (100%)
Set a multifunction input (MFI) as analog input:
Preset characteristic:
Define a characteristic:
Define reference value:
Analog outputs
Multi-function output MFO1
P550 10 Analog (PWM) MFO1A
P551 Analog: Voltage 100% (10 V)
P552 Analog: Voltage 0% (0 V)
P553 7 Abs. Actual Frequency(0 Hz...P419)
Other possible output values
0 Off
10 Abs. Reference Percentage
(P476+P494)
20 Abs. Iactive (active current)
30 Abs. Pactive (active power)
31 Abs. T (torque)
Via multifunction output (MFO1), output analog value:
Set MFO1 as analog output.
Set the voltage range (0...22 V) for output.
Select the value to be output.
Agile
Operating Instructions
Terminal
X12.3
MFI1 MFI2
P452 P562
P452 P562
X12.4
MFI1 MFI2
P452 P562
P452 P562
Set the characteristic points.
via MFI1:
via MFI2:
Terminal
X13.6
84
06/2013
X2/Y2
f [Hz]
MFI1: P456/P457
P419
=6
0 V
=7 0 mA
P419
MFI1: P454/P455 MFI2: P464/P465
X1/Y1
P419: Maximum frequency,
Reference percentages: Limitation to P519
= 1, 2 or 5
= 6 or 7 and
Frequency Percentage
P475 or P492 = P476 or P494 =
1 - Analog Value MFI1A
2 - Analog Value MFI2A
U [V]
24
P551 10
P552 0
0%
P553=7 0 Hz
32 Abs. Inside Temperature
33 Abs. Heat Sink Temperature
51 DC-Link Voltage
52 V (output voltage)
(Not all functions are listed.)
After first commissioning
Commissioning
(Factory setting)
X2/Y2
MFI2: P466/P467
+10 V U [V]
+20 mA
X1/Y1
Factory setting
(Factory setting)
100%
P419 (f )
max
