7.10.11.1 Copying using the operator panel

Storage on a memory card
Parameter values of a frequency inverter can be saved on standard digital memory cards (Bonfiglioli
Vectron "Resource Pack") and uploaded on another frequency inverter.
SAVE Save parameter values in a file on the memory card.
• On the operator panel in menu "Copy", select item "Save".
• Confirm by pressing "ENT". The number of the next available file is displayed.
• Confirm by pressing "ENT". The parameter values are copied to the file on the memory card.
A progress indicator indicates the parameter numbers the values of which are currently copied to the
memory card.
Please note, that always the highest existent number on the memory card is used to
determine the next free data file number.
New Data file number = Highest existent Data file number + 1
If a file with number 9999 already exists, the data set to be stored cannot be stored
correctly. Always take care, that at least number 9999 is available before Saving.
LOAD Uploading parameter values from memory card to a frequency inverter.
• On the operator panel in menu "Copy", select item "Load".
• Confirm by pressing "ENT". Using the arrow buttons, select the file you want to upload to the
frequency inverter.
• Confirm by pressing "ENT". The parameter values of the selected file are uploaded to the fre-
quency inverter.
A progress indicator indicates the parameter numbers the values of which are currently uploaded to
the frequency inverter.
Agile
Operating Instructions
SAVE
Number of next
available file
File selection
254
06/2013
Parameter descriptions
LOAD
Progress indicator
Progress indicator
Special functions
