Parameter descriptions
If the same setting is selected for parameter
Reference Frequency Source 2
the reference value is the single value of the selected reference value source.
Selection of source for reference value:
Reference Frequency Source 1
Reference Frequency Source 2
0 - Zero
1 - Analog Value MFI1A
2 - Analog Value MFI2A
3 - Fixed Frequency
4 - Motorpot. via Digital Inputs
5 - Keypad-Motorpot.
10 - Repetition Frequency
20 - Fieldbus Reference Value
30 - Technology Controller
40 - electr. Gear
2501 - PLC Output Frequency 1
Reference Values
492, the reference value is not doubled. In this case
475
492
Reference value is zero.
Multifunction input 1 is the reference value source. Via
parameter
Operation Mode MFI1
set up as an analog input (voltage or current). By setting
the voltage or current value at multifunction input 1, you
can set the output frequency. Factory setting for
ence Frequency Source 1
"Multifunction input MFI1".
Multifunction input 2 is the reference value source. Via
parameter
Operation mode MFI2
set up as an analog input (voltage or current). By setting
the voltage or current value at multifunction input 2, you
can set the output frequency. See chapter 7.6.2
"Multifunction input MFI2".
The selected fixed frequency is the reference value source.
The fixed frequency of the current data set is selected via
Fixed frequency changeover 1
67 and
changeover 2
The fixed frequency values can be set in parameters 480 ...
488. See chapter 7.5.1.3 "Fixed frequencies".
Reference value source is the function
62 and
poti up Frequency motorpoti down
frequency can be set by digital signals. See chapter 7.5.3
"Motor potentiometer".
The operator panel is the reference value source, with
keys ▲ for increasing the frequency and ▼ for reducing
the frequency. Factory setting for
492. See chapter 7.5.3.4.1 "Control via reference
source 2
frequency channel".
The frequency signal at digital input IN2D is the reference
value source. For parameter
the repetition frequency input, "20 - repetition frequency
single evaluation" or "21 - repetition frequency double
evaluation" must be selected. See chapter 7.6.7.2
"Repetition frequency input".
The reference value is transmitted via a bus system.
Profibus: The value of PZD2 is used as reference value.
CANopen: The value of object 0x6042 Target Velocity is
used as reference value.
The output of the PID controller is the reference value
source. If this source is selected for
475 or
source 1 Reference frequency source 2
technology controller is switched on. See chapter 7.9.3
"PID controller (technology controller)"
The output of the electronic gear is the reference value
source. If this source is selected for
475 or
source 1 Reference frequency source 2
electronic gear is switched on. See chapter 7.5.4
"Electronic gear".
Frequency output 1 of a PLC function block is the refer-
ence value source. See application manual "PLC".
143
Reference Frequency Source 1
Function
452, the input must be
475. See chapter 7.6.1
562, the input must be
66,
Fixed frequency
Fixed frequency changeover 3
Frequency motor-
Reference frequency
Operation mode IN2D
Reference frequency
Reference frequency
06/2013 Operating Instructions
475 and
Refer-
131.
63. The output
496 of
492, the
492, the
