BONFIGLIOLI Agile Operating Instructions Manual page 262

1511
Standby Mode
12 - Step1+I/O
13 - Step1+Communication
21 - Step1+Power Unit+I/O
Step1+ Power Unit +
22 -
Comm.
Step1+I/O + Communica-
23 -
tion
31 - Full
1
The enable inputs STOA an STOB remain functional.
2
The operation modes for communication module switch-off can be selected only if a communication module is
installed.
Agile
Operating Instructions
Standby mode is switched on. The following functions are
switched off if enable is switched off:
− the display of the operator panel
− the internal fans
− the digital and analog inputs and outputs
− the voltage output DC 10 V at terminal X13.4
Standby mode is switched on. The following functions are
switched off if enable is switched off:
− the display of the operator panel
2
− the internal fans
− an optional communication module
Standby mode is switched on. The following functions are
switched off if enable is switched off:
− the display of the operator panel
− the internal fans
− the power unit
− the digital and analog inputs and outputs
− the voltage output DC 10 V at terminal X13.4
Standby mode is switched on. The following functions are
switched off if enable is switched off:
− the display of the operator panel
− the internal fans
− the power unit
− an optional communication module
Standby mode is switched on. The following functions are
switched off if enable is switched off:
− the display of the operator panel
− the internal fans
− the digital and analog inputs and outputs
− the voltage output DC 10 V at terminal X13.4
− an optional communication module
Standby mode is switched on. The following functions are
switched off if enable is switched off:
− the display of the operator panel
− the internal fans
− the digital and analog inputs and outputs
− the voltage output DC 10 V at terminal X13.4
− an optional communication module
− the power unit
262
06/2013
Energy saving
Function
1
Standby mode
