Error protocol
Code
Voltage supply for optional communication module too low. Communication via bus
system faulty.
Disconnect bus system wiring and acknowledge the error message. Check connections
and wiring of the bus system.
06
Replace the communication module if the error occurs, even if the bus system is dis-
connected.
If the communication module is replaced and the error occurs, contact the service of
BONFIGLIOLI.
Brake chopper overcurrent. Also refer to chapter 7.10.4 "Brake chopper and brake
F10 10
resist".
00 Output frequency too high, check control signals and settings.
F11
Maximum frequency achieved by control. Check deceleration ramps and connected
01
brake resistor.
The STO Diagnosis software recognized a fault in the STO switch-off paths. Check
01 wiring, connect screens. Check the EMC environment. If the fault remains, exchange
the device.
Fault of the STO diagnosis function. If the device remains after a new start up, ex-
02
change the device.
04 Internal Fault. Contact the BONFILGLIOLI customer service.
Enable signals STOA and STOB were not actuated at the same time, but with a high
05
time offset. Check the circuitry of the enable input signals.
The voltage of the STO signals is too low. Check the dimensioning of the DC 24 V sup-
06
F12
ply, that supplies the STO inputs.
The STO diagnosis software was not able to detect a clear defined STO level. Check
07 the wiring and STO triggering device. Ensure, that clear signal levels can be received
(DC 0 V / DC 24 V). If the fault persists, check if the fault persists with another drive.
The STO diagnosis software has recognized that the STO signal levels of the device
08 don't correlate to each other at different measurement points. Check the wiring, put
the screens on correctly. If the fault persists, exchange the device.
The STO diagnosis software recognized that an STO signal is too high inside the de-
.
09 vice Check the wiring; apply a clear defined signal level (0V / 24 V). If the fault per-
sists, exchange the device.
00 Earth fault on output, check motor and wiring.
F13
10 Minimum current monitoring, check motor and wiring.
01 Reference value on multifunctional input 1 faulty, check signal.
02 Reference value on multifunctional input 2 faulty, check signal.
07 Overcurrent on multifunctional input 1, check signal.
08 Overcurrent on multifunctional input 2, check signal.
No actual value for technology controller. Missing actual value was reported according
09
F14
to setting for
Temperature measurement with KTY measuring resistor defective. Check signal and
50
measuring resistor.
External error; drive responded according to parameter setting for
535. Error was triggered via the logic signal or digital input signal assigned to
54
error
parameter
10 Communication error according to parameter
F20
11 Communication error according to parameter
Error list
Error messages
Brake chopper
Output frequency
Enable
Motor connection
Control connection
Operation mode actual value failure
183.
External error
Modbus and VABus
327
