The behavior of the PID controller is set with:
− Proportional part
Amplification
− Integral part
Integral Time
− Differential part
Derivative Time
Reference percentage channel is shown (simplified). See chapter 7.5.2 "Reference percentage chan-
nel".
Application examples
Application
Pressure control
Flow rate control
Temperature control
Via dataset changeover via control contacts, the PID controller can be adjusted to different operating
points.
476,494 Reference percentage source, PID desired set value input
The desired set value source of the control can be selected via parameter
476 or
Source 1 Reference Percentage Source 2
chapter 7.5.2 "Reference percentage channel".
Agile
Operating Instructions
444
445
446
The pressure in a process is kept at a constant level by means of a pres-
sure sensor.
The flow rate in a process is kept at a constant level by means of a flow
sensor.
The temperature is kept at a constant level by controlling a fan by means
of a thermostat.
494. The values of both parameters are added. See
222
06/2013
Parameter descriptions
441
Function
Reference Percentage
Control functions
