Parameter list
No.
417 Frequency Switch-off Limit
418 Minimum Frequency
419 Maximum Frequency
420 Acceleration (Clockwise)
421 Deceleration (Clockwise)
422 Acceleration Anticlockwise
423 Deceleration Anticlockwise
424 Emergency Stop Clockwise
425 Emergency Stop Anticlockwise
426 Maximum Leading
430 Ramp Rise Time
435 Operation Mode
436 Ramp-up Time
437 Ramp-down Time
438 Traverse Amplitude
439 Proportional Step
Operation Mode Actual Value Fail-
440
ure
441 Max. I-component
442 Maximum Frequency
443 Minimum Frequency
444 Amplification
445 Integral Time
446 Derivative Time
Reference frequency channel/blocking frequencies
447 1st Blocking Frequency
448 2nd Blocking Frequency
449 Frequency Hysteresis
450 Tolerance Band
451 Filter Time Constant
452 Operation Mode MFI1
453 Error/Warning Behaviour
454 Characteristic Curve Point X1
455 Characteristic Curve Point Y1
456 Characteristic Curve Point X2
457 Characteristic Curve Point Y2
458 Operation Mode
459 Signal Source
460 Positioning Distance
461 Signal Correction
462 Load Correction
463 Activity after Positioning
464 Waiting Time
Parameters (Menu PARA)
Parameters
Description
Error/warning behavior
Frequency Limits
Frequency ramps
Traverse function
PID controller (technology controller)
Multifunction input 1 (MFI1)
Positioning
345
Unit Setting range
Hz 0.00 ... 999.99
Hz 0.00 ... 999.99
Hz 0.00 ... 999.99
Hz/s 0.00 ... 9999.99
Hz/s -0.01 ... 9999.99
Hz/s -0.01 ... 9999.99
Hz/s -0.01 ... 9999.99
Hz/s 0.01 ... 9999.99
Hz/s 0.01 ... 9999.99
Hz 0.01 ... 999.99
ms 0 ... 10000
- Selection
s 0.01 ... 320.00
s 0.01 ... 320.00
% 0.01 ... 50.00
% 0.01 ... 50.00
- Selection
Hz 0.00 ... 999.99
Hz 0.00 ... 999.99
Hz -999.99 ... 0.00
- -15.00 ... 15.00
ms 0 ... 32767
ms 0 ... 1000
Hz 0.00 ... 999.99
Hz 0.00 ... 999.99
Hz 0.00 ... 100.00
% 0.00 ... 25.00
ms Selection
- Selection
- Selection
% 0.00 ... 100.00
% -100.00 ... 100.00
% 0.00 ... 100.00
% -100.00 ... 100.00
- Selection
- Selection
6
U 0.000 ... 1 10
ms -327.68 ... 327.67
- -32768 ... 32767
- Selection
6
ms 0 ... 3.6 10
06/2013 Operating Instructions
Chapter
7.4.4
7.5.1.1
7.5.1.1
7.5.1.4
7.5.1.4
7.5.1.4
7.5.1.4
7.5.1.4
7.5.1.4
7.5.1.4
7.5.1.4
7.10.8
7.10.8
7.10.8
7.10.8
7.10.8
7.9.3
7.9.3
7.9.3
7.9.3
7.9.3
7.9.3
7.9.3
7.5.1.5
7.5.1.5
7.5.1.5
7.6.1.1.2
7.6.1.1.3
7.6.1
7.6.1.1.3
7.6.1.1.2
7.6.1.1.2
7.6.1.1.2
7.6.1.1.2
7.3.7
7.3.7
7.3.7
7.3.7
7.3.7
7.3.7
7.3.7
Agile
