677 Amplification
678 Integral Time
The proportional and integrating part of the voltage controller can be set via parameters
677 and
Integral Time
The controllers are P and I controllers in the corresponding settings.
Parameters
No. Description
677 Amplification
678 Integral Time
The factory settings depend on the selected configuration and control procedure.
1)
30 = 110
Configuration
2)
30 = 410, 610
Configuration
7.9.3

PID controller (technology controller)

The PID controller can be used for process control. The connection of PID desired set value and PID
real value of the application with the functions of the frequency inverter enables process control with-
out further components. In this way, applications such as pressure, volume flow or speed control can
be implemented easily.
Starting the PID controller: Set one of the following parameters.
Parameters
Reference Frequency Source 1
or
Reference Frequency Source 2
Desired set value for PID controller: Set one of the following parameters.
Parameters
Reference Percentage Source 1
or
Reference Percentage Source 2
For example: analog desired set value at MFI2A.
(
Reference Percentage Source 1
MFI2A")
Set terminal X12.4 as analog input.
Parameters
Operation Mode MFI2
1
MFI1A: Multifunction input at terminal X12.3.
2
MFI2A: Multifunction input at terminal X12.4.
Agile
Operating Instructions
678. The control functions are deactivated by setting the parameters to 0.
Min.
0.00
0 ms
Factory setting
475 1 - Analog Value MFI1A
492
5 - Keypad-Motorpot.
Factory setting
476
1 - Analog Value MFI1A
494 5 - Keypad-Motorpot.
476 or
Reference Percentage Source 2
Factory setting
562 4 - Digital PNP (active: 24 V)
06/2013
Setting
Max. Fact. sett.
30.00
8 ms
10000 ms
23 ms
30 - Technology Controller
30 - Technology Controller
1
Select analog input or percent-
age. For example "2 - Analog
Value MFI2A"
Percentage".
Voltage input or current input.
See chapter 7.6.2 "Multifunction
input MFI2".
220
Parameter descriptions
Amplification
1)
1
2)
2
1)
2)
Set
Set
2
or "3 - Fixed
494 = "2 - Analog Value
Set
Control functions
