Starting Behavior - BONFIGLIOLI Agile Operating Instructions Manual

Parameter descriptions
Lock the Reference value facilities of the control panel
If the setting possibility of the reference frequency at the operator panel must be locked: For the fol-
lowing parameters the setting "5 - Keypad-Motorpot." must not be selected.
−
Reference Frequency Source 1
−
Reference Percentage Source 1
Set parameter
Set Password
password".
NOTE
The setting of parameter
keypad. Start, Stop, Change direction of rotation, Poti F and Poti P are still available.
7.3.2

Starting behavior

The starting behavior of the machine can be configured. In Configuration 110 (V/f control of asyn-
chronous motor) the starting behavior can be set via parameter
In the field-orientated control method of configurations 410 (asynchronous motor) and 610 (synchro-
nous motor), the starting behavior can be set via the limits
Current during flux-formation
Parameter of starting behavior in the configurations
30
Configuration
620
621
622
623
624
625
779
780
781
620 Operation mode (starting behavior)
The parameter
Operation mode
"110 - IM: sensorless control" (V/f control of asynchronous motor) is selected. Depending on the op-
eration mode selected, the motor is magnetized first or a starting current is impressed. The voltage
drop across the stator resistance which reduces the torque in the lower frequency range can be com-
pensated by the IxR compensation.
To ensure the correct function of the IxR compensation, the stator resistance is determined during the
guided commissioning (Setup). The IxR compensation is only activated when the stator resistance was
determined correctly.
620
Operation mode
0 - Off
Operational Behavior
475,
Reference Frequency Source 2
476,
Reference Percentage Source 2
27 to prevent the resetting of parameters. Refer to chapter 7.1.3 "Set
27 only does not lock the control facilities of the
Set Password
781.
U/f DMR
Asynchronous
motor
110 410
x
x
x
x x
x x
x x
x
x x
x x
620 for the starting behavior is available if
During startup, at an output frequency of 0 Hz, the voltage is set via
parameter
Starting voltage
output frequency are changed according to the control method.
The break-away torque and the current at the start are determined by
the adjusted starting voltage. It may be necessary to optimize the start-
ing behavior via the parameter
123
492
494
Operation mode
Maximum flux-formation time
DMR
Synchronous
motor
610
x
x
x
x
x
x
Starting behavior
600. After this, the output voltage and the
600.
Starting voltage
06/2013 Operating Instructions
620.
780 and
30 =
Configuration
Agile
