Motor Protection By I 2 T- Monitoring - BONFIGLIOLI Agile Operating Instructions Manual

Unlike the operation of a conventional motor circuit breaker which disconnects the equipment to be
protected immediately if the trigger threshold is reached, this function provides the possibility of issu-
ing a warning instead of disconnecting the equipment immediately.
The rated current of the motor circuit breaker refers to the rated motor current stated via parameter
371 of the corresponding data set. The rated values of the frequency inverter are to
Rated Current
be considered accordingly when it comes to dimen-sioning the application.
The function of the motor circuit breaker can be linked to different data sets. In this way, it is possible
to operate different motors via one frequency inverter. Thus, each motor can be equipped with its
own motor circuit breaker.
In case a motor is operated via the frequency inverter for which some setting values, e.g. minimum
and maximum frequency, are changed via the data set switch-over, only one motor circuit breaker
may be installed. This functionality can be set for single or multi-motor operation via parameter
571.
ation Mode
571
Operation Mode
0 - Off
K-Char.,Mul.Motor
1 -
Op.,Err.Sw.Off
K-
2 - Char.,Sing.Motor,Err.
Sw.-Off
K-Char.,Multi-Motor
11 -
Op.,Warning
K-Char.,Single-
22 -
Motor,Warning
I²t, Single-Motor,
42 -
Error Switch Off
I²t, Multi-Motor Op-
51 -
eration, Warning
I²t, Single-Motor,
53 -
Warning
I²t, Multi-Motor Op-
eration,
61 -
Warning and Error
Switch Off
I²t, Single-Motor,
62 - Warning and Error
Switch Off
K-Char.,Multi-Motor
101-
Op.,Warning, stored
Char.,Sing.Motor,Err.
102-
Sw.-Off, stored
K-Char.,Multi-Motor
111- Op.,Warning,
stored
K-Char.,Single-
122 - Motor,Warning,
stored
K-Char: K-characteristic of the motor circuit breaker
Agile
Operating Instructions
The function is deactivated. Factory setting.
In each of the four data sets, the rated values are monitored. Over-
loading the drive is prevented by the fault switch-off "F0401".
The rated values in the first data set are used independently of the
active data set. Overloading the drive is prevented by the fault switch-
off "F0401".
In each of the four data sets, the rated values are monitored. Over-
loading the drive mechanism is signaled by a warning message
"A0200".
The rated values in the first data set are used independently of the
active data set. Overloading the drive mechanism is signaled by a
warning message "A0200".
Please check chapter 7.10.6.2 „Motor Protection by I2t- monitoring"
Please check chapter Motor Protection by I
„Motor Protection by I2t- monitoring"
Please check chapter 7.10.6.2 "Motor Protection by I
Please check chapter 7.10.6.2 "Motor Protection by I2t- monitoring"
Please check chapter 7.10.6.2 "Motor Protection by I
In each of the four data sets, the rated values are monitored. Over-
loading the drive is prevented by the fault switch-off "F0401". The
internal state of the Motor circuit breaker is stored reset stable. These
settings are to be used for short-time mains shut downs.
The rated values in the first data set are used independently of the
active data set. Overloading the drive is prevented by the fault switch-
off "F0401". The internal state of the Motor circuit breaker is stored
reset stable. These settings are to be used for short-time mains shut
downs.
In each of the four data sets, the rated values are monitored. Over-
loading the drive mechanism is signaled by a warning message
"A0200".The internal state of the Motor circuit breaker is stored reset
stable. These settings are to be used for short-time mains shut downs.
The rated values in the first data set are used independently of the
active data set. Overloading the drive mechanism is signaled by a
warning message "A0200". The internal state of the Motor circuit
breaker is stored reset stable. These settings are to be used for short-
time mains shut downs
246
06/2013
Parameter descriptions
Function
2
t- monitoring 7.10.6.2
2
t- monitoring"
2
t- monitoring"
Special functions
Oper-
