3.3.2.7 Viewing a Port's Routing Table
To view a port's routing table:
1.
2.
3.
CHAPTER •
3 SecureSync User Reference Guide Rev. 18
In the Add Route panel, fill in the fields.
Net Address —This is the router to which the port connects.
Prefix —This is the subnet mask in prefix form. See "Network Configuration Without
DHCP" on page 32 for information on subnet masks.
Router Address —This is the IPv4 Gateway address.
Click the Add Route button at the bottom of the screen.
NOTE – In order for you to set up a static route, the Ethernet connector must be phys-
ically connected to the network.
To delete a static address, click the Delete button in the entry for that address in the
ACTION column of the Static Routes panel.
Navigate to the Network Management screen through the MANAGEMENT/NETWORK
dropdown menu.
The Ports panel will show the Ethernet ports you have available and their connection
status.
In the Ports panel, locate the port you want to configure, and click the TABLE button. The
Static Routes window will display.
3.3 NETWORK Setup Pages
