Main tab: Status information
The Main tab provides the following information:
CHAPTER •
5 SecureSync User Reference Guide Rev. 18
Ethernet Status : Whether the module is connected to a network through Ethernet.
Green=Connected. The speed of the connection is indicated.
Orange=Not connected.
Status : Master/Slave mode of the card.
Transmission/Clock Mode : Transmission mode and master/slave mode.
Domain Number : The current PTP Domain Number.
Current IP Address : The IP address currently being used by the PTP interface.
MAC Address : The MAC address currently being used by the PTP interface.
5.5 Network Interface Option Cards
