5.
4.10.3

The NTP Jitter Performance Graph

To view the NTP Jitter performance graph:
1.
2.
CHAPTER •
4 SecureSync User Reference Guide Rev. 18
To select the statistics for a particular day, select a date from the drop-down list in the
Select Day for Statistics field (highlighted in green in the illustration above). The default
date is the present date. Click the Apply button.
To display a higher resolution graph of a shorter time frame, move one or both of the
two sliders inwards.
Navigate to the MANAGEMENT/NETWORK/NTP Setup screen.
In the NTP Status Summary panel locate the Jitter graph.
4.10 NTP Status Monitoring
253
