5.1 Option Cards Quick Reference Guide
5.1.6

Configuring the Settings of an Input or Output

The configurable settings of any SecureSync input or output interface are accessible through the
Edit window of the option card to which the input or output belongs. The Edit window can be
accessed in several ways; the procedure below describes the standard way:
1.
Identify the name of the card, (e.g., PPS OUT, 4-BNC ), and verify the name of the input or
output you want to configure (e.g., PPS Output 1 ).
2.
Navigate to the INTERFACES/OPTION CARDS drop-down menu, and click the list entry
of the option card identified above. The option card's Status Summary panel opens:
3.
Click on the GEAR button next to the input or output you wish to configure (as verified in
Step 1 of this procedure). The Edit window of the input or output opens:
290
NOTE – If you have only one input or output of any type, SecureSync will number
that input or output 0. Additional inputs or outputs will be numbered 1 or above.
