To rack mount the SecureSync unit:
1.
2.
3.
2.6.1

Desktop Operation

SecureSync units can also be operated on a desktop in a HORIZONTAL, RIGHT-SIDE-UP pos-
ition. The location needs to be well-ventilated, clean and accessible.
2.7

Power Connection

Depending on the equipment configuration at time of purchase, SecureSync can be powered from
an AC input, a DC input or with both AC and DC input (DC input is an option). Supplying both AC
and DC input power provides redundant and automatic power switchover in case one or the other
input power sources is lost.
Before connecting power to the unit, be sure that you have read all safety information detailed in
section "SAFETY" on page 18.
2.7.1

Input Power Selection

As long as the AC input power is present, and SecureSync is equipped with the DC redundancy
option, it will utilize the AC power source over DC power.
CHAPTER •
2 SecureSync User Reference Guide Rev. 18
Attach an MP09-0003-0030 equipment rack handle to the front of each 1165-1000-0714 rack
mounting bracket, using the holes nearest the right angle bend of the 1165-1000-0714 rack
mounting bracket, with the #2 size Phillips screwdriver, using 2 each of the H020-0832-
0406 #8-32 flat head Phillips screws.
Attach the 1165-1000-0714 rack mount brackets to the sides of the SecureSync with the
rack mounts ears facing outward, aligned with the front edge of the SecureSync front panel.
Use the #2 Phillips screwdrivers, using 3 each of the HM20R-04R7-0010 M4 flat head Phil-
lips screws.
Secure the rack mount brackets to the rack using the #10-32 rack mount screws and #2 Phil-
lips head screwdriver, 2 each per side of the rack.
Caution: For safety reasons, the SecureSync unit is intended to be operated in a
HORIZONTAL POSITION, RIGHT-SIDE-UP, that is with the keypad to the left side
and the 4-line information display and the time display on the right side.
If AC and DC power are both applied, AC power is used.
If DC power is applied, but AC power is not, then DC power will be used.
If AC and DC power are both present, but AC power is subsequently lost, SecureSync will
automatically switch to using the DC power input.
2.7 Power Connection
