5.4 Time Code Option Cards
Pin Assignments
Pin No. Signal
1
2
3
4
5
6
7
8
9
10
11
12
13
Table 5-16:
5.4.3.2 STANAG Output: Edit Window
To configure a STANAG output , go to its Edit window. For instructions, see: "Configuring the Set-
tings of an Input or Output" on page 290.
The Web UI list entries for these cards are: STANAG Out and STANAG Out, Isolated .
The outputs are named: Stanag HQ Output [number] .
352
Function
GND Ground
TOD1+ TOD1 RS-485+ Out 15
NC -
TOD2+ TOD2 RS-485+ Out 17
NC -
GND Ground
GND Ground
NC -
1PPS+ 1PPS RS-485+ Out 22
TFD Time Fault Discrete 23
TOD1 TOD1 TTL Out
GND Ground
TOD2 TOD2 TTL Out
Models 1204-11, -25: DB-25 pin-out
NOTE – SecureSync starts numbering I/O ports with 0 (only 1PPS and 10 MHz out-
puts start at 1, because of the built-in outputs).
Pin No. Signal Function
14 TOD1- TOD1 RS-485- Out
NC -
16 NC -
TOD2- TOD2 RS-485- Out
18 NC -
19 NC 5 MHz Out (1204-11 Only)
20 NC -
21 1PPS- 1PPS RS-485- Out
NC -
GND Ground
24 1PPS 1PPS TTL Out
25 GND Ground
