5.5.3.1 PTP Master/Slave[1204-12]: Specifications
Figure 5-41:
5.5.3.2 PTP Master/Slave [-12]: Edit Window
1.
CHAPTER •
5 SecureSync User Reference Guide Rev. 18
A Slave Clock , in which case it provides to the SecureSync device a time and syn-
chronization reference retrieved from information carried by the PTP packets received via
the Ethernet port.
A Master/Slave Clock , in which case the PTP option card can change mode according to
priority and quality criteria compared with the other PTP Clocks on the network.
Inputs/Outputs : (1) Configurable as Input or Output
Signal Type and Connector : RJ-45
Management : Web UI
Resolution : 8ns (±4ns) packet time stamping resolution
Accuracy : 30 ns accuracy (3σ) Master to Slave, via crossover cable
Networking speeds : 10 Mb/s, 100 Mb/s
Supported PTP Versions : PTP 2 (IEEE 1588-2008)
PTP Profiles supported: Default
Transmission modes : Unicast, Multicast [default]
Maximum Number of Cards : 6
Ordering Information : 1204-12: PTP/Precision Timing Protocol Option Module
Model 1204-12 option card rear plate
To configure this option card, go to its Edit window. For instructions, see "Configuring the
Settings of an Input or Output" on page 290.
