5.2 Time and Frequency Option Cards
The Edit window allows the configuration of the following settings:
Signature Control : Controls when the output will be present; see "Signature Control" on
page 201.
5.2.4.3 Frequency Output: Status Window
To view the settings of a Frequency output , go to its Status window. For instructions, see: "View-
ing the Configuration of an Input or Output" on page 288.
The Web UI list entry for this card is named: 1/5/10 MHz BNC.
The connector numbers are: J1...J3.
The Status window displays the following settings:
Signature Control : Controls when the output will be present. See also: "Signature Control"
on page 201.
Frequency : The frequency of the output: 1MHz, 5MHz or 10 MHz, depending on the card
model.
For more information on monitoring installed option cards, see: "Monitoring the Status of Option
Cards" on page 245.
312
NOTE – SecureSync starts numbering I/O ports with 0 (only 1PPS and 10 MHz out-
puts start at 1, because of the built-in outputs).
