4.7 Outputs Status Monitoring
2.
The pop-up Status window will display a list of all outputs of the selected category.
To display more detailed information about a particular output, click the corresponding INFO
button.
To edit the settings of a given output, click the GEAR button (see also "Outputs Status Mon-
itoring" on page 240.)
To refresh the information displayed, click the REFRESH button (circling arrows icon).
In the illustration of the rear panel, click on a connector to highlight the corresponding list
entry.
4.7.3

Displaying Output Settings

The outputs installed in your SecureSync unit have specific settings that can be reviewed, and—to
some extent—edited.
To display the settings of an output:
242 CHAPTER •
4 SecureSync User Reference Guide Rev. 18
