The window contains 2 tabs:
Main (the default)
Satellite Data
Under the Main tab, the following information will display:
Manufacturer/Model —The manufacturer and/or model of the GNSS receiver
Validity —The two "light" icons will indicate the validity of the available signals:
TIME
1PPS
" On " (green) indicates a valid signal. " Off " indicates no valid signal.
Receiver Mode:
Single Satellite
Standard
Mobile
Survey Progress —Current status:
ACQUIRING (x Satellites)—red
SURVEYING (x %)—yellow; remains at 1 % if no satellites are in view
COMPLETE—green
Number of Tracked Satellites —The number of satellites being tracked by
SecureSync
Offset —As set by the user, in nanoseconds.
Antenna Sense —This will display:
"OK" (green)
"Open"—Check the antenna for the presence of an open.
"Short"—Check the antenna for the presence of a short.
Position —SecureSync's position by:
Latitude—In degrees, minutes, seconds
Longitude—In degrees, minutes, seconds
Altitude—In meters
Receiver Constellation —GPS, GPS/GLONASS, or GLONASS
Client A-GPS Status —A-GPS is ENABLED and running, or DISABLED
Client A-GPS Data — External A-GPS data is AVAILABLE, or UNAVAILABLE
Server A-GPS Status —The Rinex Server feature is ENABLED and running, or
DISABLED
