Gigabit Ethernet - Spectracom SecureSync User Reference Manual

5.5.1

Gigabit Ethernet [1204-06]

This option card provides SecureSync with three 10/100/1000 Base-T network interfaces, in addi-
tion to the standard 10/100 Base-T network interface.
5.5.1.1 Gigabit Ethernet [1204-06]: Specifications
Figure 5-39:
5.5.1.2 Accessing the Network Management Screen
In order to monitor and manage Ethernet on SecureSync:
CHAPTER •
5 SecureSync User Reference Guide Rev. 18
Inputs/Outputs : (3) Gigabit Ethernet (10/100/1000 Base-T)
Connectors : RJ-45 (3x)
Management : Enabled or Disabled (NTP server only)
Maximum Number of Cards : 1
Ordering Information : 1204-06: Gigabit Ethernet (3X) Module
1204-06 option card rear plate
Via MANAGEMENT > NETWORK , navigate to the Network Management screen: On
the right, the Ports panel will display the available Ethernet ports, and their connection
status:
5.5 Network Interface Option Cards
387
