5 SecureSync User Reference Guide Rev. 18
Identify the name of the option card, (e.g., PPS OUT, 4-BNC ) and the name of the input or
output you want to configure (e.g., PPS Output 1 ).
NOTE – If you have only one input or output of any type, SecureSync will number
that input or output 0. Additional inputs or outputs will be numbered 1 or above.
Navigate to the INTERFACES/OPTION CARDS drop-down menu, and click the list entry
of the option card identified above. The option card's Status Summary panel opens:
Click on the INFO button next to the input or output whose settings you wish to review. The
Status window of the input or output opens:
Information about the settings of a specific interface can be found in the corresponding
option card section, see "Option cards listed by their ID number" on page 286.
If you want to change any of the settings shown in the Status window, click the Edit button
in the lower-left corner, in order to open the Edit window:
5.1 Option Cards Quick Reference Guide
