Main tab settings
Settings to configure under the Main tab:
Ethernet tab settings
Settings to configure under the Ethernet tab:
CHAPTER •
5 SecureSync User Reference Guide Rev. 18
Transmission Mode : (See also: "Transmission Modes" on page 416)
Unicast
Multicast
Minicast
Clock Mode : The Master/Slave Mode of the PTP Module. Will be one of:
Slave
Master
Disabled
The default value is Slave .
Domain Number : Sets the current PTP Domain Number, as defined in IEEE Std 1588-
2008 Section 7.1. Range: [0,255]. Default setting: 0
Master Clock IP Address : Static IP address of the unicast Master Clock. In the format
"#.#.#.#" with no leading zeroes or spaces, where each '#' is a decimal integer from the
range [0,255].
Transport Protocol : Selects the transport protocol used for PTP Packets. Possible values
are:
IPv4 (The default): Internet Protocol version 4 (Layer 3 protocol).
802.3/Ethernet: IEEE802.3/Ethernet Protocol (Layer 2 protocol).
Operating limitations: The IEEE802.3/Ethernet Protocol is not supported in Unicast trans-
mission mode.
Enable DHCP : This is a checkbox to enable or disable the delivery of IP addresses from a
DHCP Server. The default setting is enabled (the box is checked).
Static IP Address : When a DHCP server is not requested or is requested but not available,
the PTP Module will use this IP address. In the format "#.#.#.#" with no leading zeroes or
spaces, where each '#' is a decimal integer from the range [0,255].
Network Mask : When a DHCP server is not requested or is requested but not available,
the PTP Module will use this Network Mask. In the format "#.#.#.#" with no leading zeroes
or spaces, where each '#' is a decimal integer from the range [0,255].
Default Gateway : When a DHCP server is not requested or is requested but not available,
the PTP Module will use this Default Gateway. In the format "#.#.#.#" with no leading zer-
oes or spaces, where each '#' is a decimal integer from the range [0,255].
5.5 Network Interface Option Cards
