2.11 DHCP Network Configuration
To modify a parameter, highlight the menu option and press the ENTER button. The "O" data is the
current old setting and the "N" data is the new setting. You can only change the "N" setting in all
menus. Use the UP and DOWN arrow keys to scroll through all possible parameter values.
When editing a sequence of numbers, use the LEFT and RIGHT arrow keys to select other digits.
When the parameter is correct, press ENTER to load the new value. You will be asked to confirm
the setting change. Press ENTER to accept or BACK to cancel the parameter change. All entered
values are stored in memory and restored after a power cycle.
2.10.4

Unlocking the Front Panel Keypad

If the front panel keypad is locked, the following sequence will locally unlock the keypad for use.
Alternatively, the front panel can also be locked/unlocked via the SecureSync Web UI, see "Lock-
ing/Unlocking the Front Panel Keypad" on page 182.
2.11

DHCP Network Configuration

2.11.1 Opening the Web UI
On a network using DHCP, SecureSync's IP address will be assigned automatically once it is con-
nected to the DHCP server. This address and other network information are displayed on the front
panel when the device boots up.
1.
On a computer connected to the SecureSync network, start a Web browser, and enter the
above-mentioned IP address of your SecureSync into the address field of the browser.
2.
Log in as an administrator (see: "The Administrator Login Password" on page 215).
Unless you are using DNS in conjunction with DHCP (with the client configured using
SecureSync's hostname instead of IP address), Spectracom recommends to disable DHCP for
SecureSync, and change the IP address to a static address. Failure to do this will result in a loss of
time synchronization, should the DHCP server assign a new IP address to SecureSync.
If you choose to use DHCP for your SecureSync, the basic network configuration is complete, and
you may proceed to "Product Configuration via the Web UI" on page 41, in order to proceed with
the configuration of your SecureSync. Otherwise, proceed to "Replacing a Dynamic with a Static
IP Address" on the facing page
30
NOTE – "Cookies" must be enabled. You will be notified, if Cookies are disabled in
your browser.
NOTE – Unless the user opens the Web UI using the default DNS name of "Spec-
tracom" (instead of using the IP address to access SecureSync), the SSL
CHAPTER •
2 SecureSync User Reference Guide Rev. 18
