Spectracom SecureSync User Reference Manual page 384

5.4 Time Code Option Cards
Signature Control : Signature Control is used to control when the HAVE QUICK mod-
ulation is present; see also "Signature Control" on page 201.
Format : Used to configure the formatting of the four available HAVE QUICK outputs. The
available output formats are as follows:
Timescale : Used to select the time base for the incoming time code data. The entered
Timescale is used by the system to convert the time in the incoming data stream to UTC
time for use by the System Time. The available choices are:
The incoming input time information may be provided as local time, but System Time may be con-
figured as UTC time, so internal computations need to be performed. With the Timescale field set
to "Local", select the name of a previously created Local Clock. The Time Zone and DST rules, as
configured in the Local Clock will be applied to the front panel time display. Refer to "Setting up a
Local Clock" on page 175 more information on Local Clocks.
Offset : Provides the ability to account for HAVE QUICK cable delays or other latencies in
the HAVE QUICK outputs. The Offset values are entered in nanoseconds (ns). The avail-
able Offset range is –500 to +500 ms.
5.4.5.5 HAVE QUICK Output: Status Window
To view the current settings of a HAVE QUICK Output , go to its Status window. For instructions,
see: "Viewing the Configuration of an Input or Output" on page 288.
The Web UI list entries for this card are: HAVE QUICK out, BNC and HAVE QUICK Out, RS-
485 .
368
STANAG 4246 HQ I
STANAG 4246 HQ II
STANAG 4372 HQ IIA
STANAG 4430 Ext HQ (Extended HAVE QUICK)
STANAG 4430 STM (Standard Time Message)
ICD-GPS-060A BCD
ICD-GPS-060A HQ
DOD-STD-1399 BCD
UTC : Coordinated Universal Time ("temps universel coordonné"), also referred to as
ZULU time
TAI : Temps Atomique International
GPS : The raw GPS time as transmitted by the GNSS satellites (as of July, 2015,
this is 17 seconds ahead of UTC time)
A local clock set up through the Time Management Page: This option will appear
under the name of the local clock you have set up. Refer to "The Time Management
Screen" on page 168 for more information on how to configure and read the System
Time. Local timescale allows a Local Clock to apply a time offset for Time Zone and
DST correction.
CHAPTER •
5 SecureSync User Reference Guide Rev. 18
