4.4 Status Monitoring of Input References
4.4

Status Monitoring of Input References

SecureSync's input references can be monitored in real time through the INTERFACES drop-
down menu. The menu will populate dynamically, according to which references are available.
To display all references, click on REFERENCES in the INTERFACES menu.
To display all references of a given type , click on the entry for that reference type (not
indented).
The window that opens shows the validity status for the chosen reference(s):
Click on any of the connectors shown in the rear panel illustration to highlight/identify the cor-
responding reference:
232
NOTE – If you know the individual reference or output whose status you wish to see,
you can access the Status window of that reference or output directly through the
INTERFACES/REFERENCES or INTERFACES/OUTPUTS drop-down menu.
