3.6 OTHER Setup Pages
Under the Satellite Data tab, there are two graphs:
Number of Satellites over Time —A graphical track of how many satellites were being
tracked over time.
SNR over Time —A graphical track of maximum SNR, and minimum SNR.
In both graphs, to see a legend of the graphical data, and time-specific status data, click
inside the graph, choosing the desired point in time. If necessary, increase the time res-
olution by dragging the time sliders.
A pop-up window will display the legend for that graph, and the status information for the
selected time.
214
Server A-GPS Data —A-GPS data is AVAILABLE and can be downloaded by cli-
ents, or it is UNAVAILABLE
Identified Satellite Signal Strengths —Bar graphs for all satellites detected.
Color indicates signal strength. With your mouse pointer, hover over a bar graph
to display tooltip information about type of satellite (GPS or Glonass), number of
satellite, and signal strength.
