5.1 Option Cards Quick Reference Guide
b.
If you have physical access to the actual SecureSync unit, inspect its rear panel, and com-
pare the 2-digit ID number printed in the lower left-hand corner on each option card with the
table below.
5.1.2.1 Option Card Identification by ID/Part Number
The table below will help you to locate information specific to an option card.
The table lists all option cards available at the publication date of this documentation, sorted by
their ID number . Locate the option card ID number on its cover plate, and follow the cor-
responding hyperlink in the right-hand column.
Card
ID*
01 1 PPS/freq input (TTL levels)
module
02 ASCII Time Code module (RS-
232)
03 1 PPS/freq input (RS-485 levels)
module
04 ASCII Time Code module (RS-
485)
05 IRIG module, BNC (1 input, 2 out-
puts)
06 Gigabit Ethernet module (3 ports) Gb Ethernet
08 5 MHz output module (3 outputs) 5 MHz Out
09 T1-1.544 (75 Ω) or E1-2.048 (75
Ω) module
0A T1-1.544 (100 Ω) or E1-2.048
(120 Ω) module
0B Bidirectional Communication
module
0F Alarm module
10 HaveQuick output module (TTL)
284
NOTE – * Every option card has a 2-digit ID number that can be found on its cover
plate, and in the left column below. The ID number is comprised of the two center
digits of your option card's Spectracom Part Number: 1204-0
Card Name Name in UI
"1PPS In/Out, 10 MHz In [1204-01, -
1PPS/Frequency
03]" on page 302
BNC
"ASCII Time Code In/Out [1204-02, -
ASCII Timecode
04]" on page 376
RS-232
"1PPS In/Out, 10 MHz In [1204-01, -
1PPS/Frequency
03]" on page 302
RS-485
"ASCII Time Code In/Out [1204-02, -
ASCII Timecode
04]" on page 376
RS-485
" IRIG In/Out [1204-05, -27]" on
IRIG In/Out BNC
page 338
"Gigabit Ethernet [1204-06]" on
page 387
"Frequency Out [1204-08, -1C, -26]"
on page 309
"T1/E1 Out [1204-09, -0A]" on
E1/T1 Out BNC
page 328
"T1/E1 Out [1204-09, -0A]" on
E1/T1 Out Ter-
page 328
minal
"Bi-Directional Communication, RS-
RS-485 Comm
485 [1204-0B]" on page 430
"Alarm Relay Out [1204-0F]" on
Relay Output
page 417
"HAVE QUICK Out [1204-10, -1B]" on
HAVE QUICK
page 365
Out, BNC
CHAPTER •
5 SecureSync User Reference Guide Rev. 18
0-0600.
18
See ...
