4.7 Outputs Status Monitoring
How to edit input reference settings, method 2:
1.
In the INTERFACES/REFERENCES drop-down menu, click REFERENCES , or an input ref-
erence category ("GNSS reference", for example).
2.
In the pop-up Status window, click the GEAR button next to the desired input reference.
3.
The settings window for the chosen reference will be displayed. Edit the field(s) as desired.
4.7

Outputs Status Monitoring

Per standard configuration, SecureSync is equipped with one 1PPS and 10 MHz output interface.
Additional outputs can be added by means of output option cards.
Outputs can be monitored in real time through the
populate dynamically, according to which outputs are installed
4.7.1

Monitoring the Status of All Outputs

To display a list of all the outputs installed in a SecureSync unit:
240
NOTE – A particular option card might have more than one setting that can be adjus-
ted. See "Option Cards Overview" on page 280
put or card.
for the settings of any particular out-
drop-down menu. The menu will
INTERFACES
CHAPTER •
4 SecureSync User Reference Guide Rev. 18
