5.4 Time Code Option Cards
5.4.6.4 HAVE QUICK Input: Status Window
To view the current settings of the HAVE QUICK Input (also referred to as 'Reference'), go to its
Status window. For instructions, see: "Viewing the Configuration of an Input or Output" on
page 288.
The Web UI list entry for this card is: HAVE QUICK In/Out .
The input is named: HQ Input [number] .
The Status window displays the following settings:
Reference ID : Indicates the letters used in the Input Reference Priority table for this par-
ticular input reference.
Validity : [TIME, PPS] Indicates the validity of the Time input and the PPS input. If the input
signal is valid the indicator will be green. If the signal is not valid, the indicator will be
orange.
372
GPS: The raw GPS time as transmitted by the GNSS satellites (as of July, 2015,
this is 17 seconds ahead of UTC time)
Offset: Provides the ability to account for HAVE QUICK cable delays or other laten-
cies in the HAVE QUICK outputs. The Offset values are entered in nanoseconds
(ns). The available Offset range is –500 to +500 ms.
NOTE – SecureSync starts numbering I/O ports with 0 (only 1PPS and 10 MHz out-
puts start at 1, because of the built-in outputs).
