2.10.2

Navigating the Information Display

After power initialization, press any key to go to the "Home" display. As shown in the illustration
"Keypad menu tree" below , several status and setup displays are accessible from the main
"Home" menu. To navigate through the menus, use the arrow keys to highlight a selection and then
press the ENTER button.
The main menu options and their primary functions are as follows:
2.10.3

Keypad Menu Tree

Using the front panel keypad, the 4-line information display on the unit can be configured to display
various indications, including the network settings, System Status, GNSS position, GNSS signal
information or the current date and time (or, it can even be configured to remain blank, if desired).
The figure "Keypad menu tree" below illustrates Menu Tree navigation.
Figure 2-3:
CHAPTER •
2 SecureSync User Reference Guide Rev. 18
LEFT/RIGHT arrows : Select a new item to the left or right, respectively
UP/DOWN arrows : Scroll through parameter values in edit displays
Display : Used to configure the information display
Clock : Displaying and setting of the current date and time
System : Displaying version info, system halt and reboot, reset
Netv4 : Network interface configuration
Lock : Locks the front panel keypad to prevent inadvertent operation.

Keypad menu tree

2.10 Using the Keypad and Information Display
spadmin
password
