Spectracom SecureSync User Reference Manual page 195

3.6.8.1 Accessing the Front Panel Setup Screen
SecureSync's Web UI allows you to configure the main elements on the front panel of the unit, and
to see an image of the information currently displayed on the 4-line front panel information display.
To access the front panel configuration window:
1.
2.
CHAPTER •
3 SecureSync User Reference Guide Rev. 18
The keypad , which—in conjunction with the information display—can be used to access
SecureSync's main functions directly via the unit's front panel. To prevent inadvertent
keypad operation, it can be locked and unlocked from the Web UI. Learn more about front
panel keypad operation: "Using the Keypad and Information Display" on page 28.
The information display : A 4-line LCD display that can be configured to display different
screens, and that is used in conjunction with the keypad.
The LED time display which can be configured to show the current time (UTC, TAI, GPS or
Local time scale) in either 12- or 24-hour format. By factory default, the LED will display
UTC time in 24-hour format (such as displaying "18" at 6 PM).
Navigate to MANAGEMENT/OTHER/Front Panel:
The Front Panel configuration window will display:
3.6 OTHER Setup Pages
179
