5.4.7.4 ASCII Time Code Output: Edit Window
To configure the ASCII Output , go to its Edit window. For instructions, see: "Configuring the Set-
tings of an Input or Output" on page 290.
The Web UI list entries for this card are: ASCII TIMECODE RS-232 and ASCII TIMECODE RS-
485 .
The Output Edit window allows the configuration of the following settings:
CHAPTER •
5 SecureSync User Reference Guide Rev. 18
NOTE – SecureSync starts numbering I/O ports with 0 (only 1PPS and 10 MHz out-
puts start at 1, because of the built-in outputs).
Format Group – configures the message format type. Choices are:
None (no message will be output)
Spectracom
NMEA
BBC
ICD-153
EndRun
Once selected, the Format Group may offer a choice of Formats . For more information on
supported Formats , see "ASCII Time Code Data Formats" on page 464.
Format 1 : Selects either the first of up to three, or the only format message to be output.
Format 2 : Selects the second consecutive format message to be outputted. Select "None"
if only one output format is desired. "None" will be the only choice available if Format 1 is
"None."
