5.7 Option Card Field Installation Guide
The Status window displays the following settings:
RS-485 Address : [0-31]
5.7

Option Card Field Installation Guide

Typically, SecureSync units are shipped with custom-ordered option cards pre-installed at the fact-
ory. In the event that an option card is purchased at a later time, it must be installed in the
SecureSync unit in the field by the customer.
This

option card field installation guide

cards in Spectracom SecureSync units.
5.7.1

Introduction

SecureSync time and frequency synchronization system offers customizability and expandability
via the addition of a range of modular option cards. Up to 6 option cards can be accommodated to
offer not only synchronization to a variety of input references, but also numerous types of output
signals, supporting an extensive number of traditional and contemporary timing protocols includ-
ing:
432
NOTE – SecureSync starts numbering I/O ports with 0 (only 1PPS and 10 MHz out-
puts start at 1, because of the built-in outputs).
digital and analog timing and frequency signals (1PPS, 1MHz/5MHz/10 MHz)
timecodes (IRIG, STANAG, ASCII)
high accuracy and precision network timing (NTP, PTP)
telecom timing (T1/E1), and more.
contains information and instructions for installing option
CHAPTER •
5 SecureSync User Reference Guide Rev. 18
