INSTALLATION

This Chapter guides you through the preparation of the hardware, the
installation of the SecureSync Time and Frequency Synchronization
System, its hardware interfaces, and setup tasks required to be per-
formed before configuring the product.
T he following topics are included in this Chapter:
2.1 Installation and Setup Summary
2.2 Main Installation Steps
2.3 Unpacking and Inventory
2.4 Required Tools and Parts for Installation
2.5 SAFETY
2.5.1 Safety: Symbols Used
2.5.2 SAFETY: Before You Begin Installation
2.5.3 SAFETY: User Responsibilities
2.5.4 SAFETY: Other Tips
2.6 Rack Mounting
2.6.1 Desktop Operation
2.7 Power Connection
2.7.1 Input Power Selection
2.7.2 Using AC Input Power
2.7.3 Using DC Input Power
2.8 Connecting Reference Input(s) and Network Inter-
face(s)
2.8.1 Connecting GNSS Input
2.8.2 Connecting IRIG Input
2.8.3 Ethernet Connection
2.9 Powering up the Unit
2.10 Using the Keypad and Information Display
2.10.1 Keypad Description
2.10.2 Navigating the Information Display
2.10.3 Keypad Menu Tree
2.10.4 Unlocking the Front Panel Keypad
2.11 DHCP Network Configuration
