2.7 Power Connection
The following sections discuss AC and DC power input. Connect AC and/or DC power, as
desired.
2.7.2

Using AC Input Power

Connect the AC power cord supplied in the SecureSync ancillary kit to the AC input on the rear
panel and the AC power source outlet. The AC input is fuse-protected with two fuses located in the
AC power entry module (line and neutral inputs are fused). The AC power entry module also con-
tains the main power switch for the AC power applied to the equipment.
2.7.3

Using DC Input Power

If the rear panel DC port is present, connect DC power, per the voltage and current as called out on
the label that resides above the DC power connector.
24
DANGER! — This unit will contain more than one power source if both the AC and
DC power options are present. Turning off the rear panel power switch will NOT
remove all power sources.
Caution: This equipment has Double Pole/Neutral Line Fusing on AC power.
NOTE – Important! SecureSync is earth grounded through the AC power connector.
Ensure SecureSync is connected to an AC outlet that is connected to earth ground
via the grounding prong (do not use a two prong to three prong adapter to apply AC
power to SecureSync).
NOTE – DC power is an option chosen at time of purchase. The rear panel DC input
port connector is only installed if the DC input option is available. Different DC
power input options are available (12 V
maximum or 24/48 V input with a voltage range of 21 to 60 V at 3 A maximum).
DC
Review the DC power requirement chosen, prior to connecting DC power (when the
DC port is installed, a label will be placed over the connector indicating the allowable
DC input voltage range and the required current).
DANGER! — GROUNDING:
SecureSync is earth grounded through the DC power connector. Ensure that the unit
with a voltage range of 12 to 17 V at 7 A
DC
